3D modeling and fabrication drawings for metal fabricators

From finalized plans and confirmed dimensions to a model and production package you can work with.

FABSET turns approved information into a clear model, fabrication drawings and organized project files, so you can move toward production without rebuilding the work from scratch.

Remote collaboration · Clear review process · Organized delivery

F

FABSET

Approved input. Clear documentation.

A focused technical workflow for turning confirmed plans and dimensions into an organized fabrication package.

  1. A model that clarifies the project

    See the structure, divisions and connections before production.

  2. Drawings that speak to the workshop

    Clean, organized information within the agreed scope.

  3. A project package that is easy to hand over

    Organized files for review, production and documentation.

Defined input, organized output

What enters the process

A clear scope starts with approved information and ends with deliverables agreed for the project.

Models and fabrication documentation based on approved plans, dimensions and design decisions. The service does not include structural design, stability calculations, or engineering or regulatory approval. Professional approvals required for the project must come from the relevant qualified professionals.

INPUT

What you provide after scope coordination

  • Confirmed dimensions
  • A finalized plan or a well-defined direction
  • Existing reference files provided by arrangement
  • Known fabrication requirements
  • A professional contact for questions and approvals

OUTPUT

What you receive

  • A 3D model within the agreed scope
  • Required fabrication views and details
  • Part lists and data when included in the proposal
  • Organized files in the agreed formats
  • A defined review and approval round

A clear working method

Five steps from enquiry to delivery

  1. 01

    Start with a brief enquiry

    A short summary and business contact details; project files are coordinated separately.

  2. 02

    Define scope and output

    What will be built, what will be delivered, and what remains the client’s responsibility.

  3. 03

    Model and organize

    Build the model and prepare the agreed material.

  4. 04

    Review

    A structured pass through questions, corrections and approvals.

  5. 05

    Receive an organized package

    Delivery of files and drawings in the agreed formats.

Project readiness

Is the project ready for modeling?

A good fit when

  • The dimensions have been checked and confirmed
  • The product form and design intent are clear
  • An organized model or production documentation is needed
  • A professional contact can answer questions and approve decisions

Needs preparation first when

  • Site dimensions are still missing
  • The structure or concept is still open
  • Engineering calculations or structural approval are required
  • No one is available to approve changes and corrections

Not sure? Contact us with a short, non-confidential summary and we will check the initial fit.

Check project fit

Focused technical studio

Technical precision, with a practical working approach

FABSET gives metal fabricators and professionals an organized way to move a project from approved design to a model and clear fabrication material. The work stays practical: understand how the project is meant to be built, identify missing information early, and deliver files that remain easy to navigate beyond a single screen.

Practical details

Frequently asked questions

01What should I send for an initial enquiry?

Begin with a short, non-confidential summary and business contact details only. If the project appears suitable, we will coordinate the secure and necessary project material separately.

02Can we work remotely?

Yes. The process is structured for remote coordination, questions, review and approval. Responsibility for dimension accuracy and design approval remains as agreed.

03Which files will I receive?

File types are defined according to the project’s needs and listed in the proposal. They may include a 3D model, drawing PDFs and other files agreed in advance.

04How long does a project take?

The schedule is set after reviewing the coordinated material and understanding the project’s complexity. A clear target date is provided before work begins.

05What happens if corrections are needed?

The number and scope of review rounds are defined in the proposal. A substantial design or dimension change after work begins may affect the scope and schedule.

06Does the service include engineering design or approval?

No. FABSET translates approved inputs into models and fabrication documentation. Where approval by an engineer, architect or another qualified professional is required, it must be obtained separately; client approval alone does not replace it. Design questions or inconsistencies are referred back for clarification and approval before work continues.

07Can the project remain confidential?

Yes. Begin without confidential files. Limits on use, publication and sharing, together with the method for transferring necessary project material, can be agreed before materials are provided.

CONTACT

Start with a short, non-confidential brief.

Send a few lines about the project and we’ll check whether it’s a fit.

Email us[email protected]

Your details will be used only to respond and assess project fit. Do not send sensitive information or confidential files at this stage. Privacy Policy.

The service is based on approved plans and dimensions and does not constitute engineering approval.
